factory price gas fired aluminum melting furnace

FOB Reference Price:Get Latest Price
US $7,000-7,515 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Crucible furnace
Usage:
Melting Furnace
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
GreenVinci
Model Number:
GP250
Voltage:
380V
Power(W):
10kw
Dimension(L*W*H):
1450*950mm
Weight:
2000kg
Certification:
CE/SGS/ISO
Warranty:
1 YEAR
After-sales Service Provided:
Engineers available to service machinery overseas
Melting Capacity:
6-80kg/h
Liquid Capacity:
250kgs
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case /safety packing
Port
FoShan/GuangZhou/ShenZhen
Lead Time :
25 days after deposit

GreenVinci Crucible natural gas aluminum melting furnace is a Crucible furnace, with burning, melting, insulation capabilities , is currently the most perfect design, highest degree of automation, with a number of patented melting furnace. Mainly used in melting or smelting aluminum, zinc, lead, tin, cadmium and other low-melting non-ferrous metals and alloys, and supporting the use of die-cast function well; also can be used for liquid aluminum insulation, in addition to gas, refining. With the advantage of high acceptance by operators , environmental friendly ,low operating cost, simple operation and maintenance .



Application Range:
Widely supporting mechanical and aluminum die-casting plant, adapted to industrial aluminum, zinc, lead, tin, cadmium and other low melting point non-ferrous metals melting and insulation , but also as aluminum scrap, industrial aluminum and various metal scrap melting into the ingots.



Product feature

1)  natural gas as an energy source, tons of aluminum melting heat preservation cost of about 80             cubic meters of natural gas, is one of the most clean energy recognized by the state                               environmental protection department.

2)  the furnace body structure is strong, the internal grade refractory material, durable and durable,         the outside temperature of the furnace body is not higher than 60 degrees.

3)  equipped with aluminum water leakage alarm power-off device, even accidentally leaked aluminum       water is not too much, for Guo, lift the alarm can continue to use.

4)  the temperature control system uses the artificial intelligence temperature controller, the                       temperature is accurate, the analog quantity electric current, the switch output, the                               intellectualized control.

5)  the crucible material can be arbitrarily selected according to the requirements of the customers.

6)  can be customized according to the client's 160-800 ton model, and can be used in conjunction           with automatic soup machine.









Project:
